Features and Benefits:
3-Cylinder, 2-Stage Pump
Commercial Grade
7.5hp, 1740 RPM Motor
80 Gallon Vertical Tank(Made in the USA)
Air Output 145-175 PSI
Extremely Quiet Operation
Magnetic Starter Included, Adding ToLongevity Of The Unit
Set of Vibro-Isolation Pads Included
Hands Free Tank Drain Extension
Compressor Oil Drain Extension Tube
Finned Tank Inlet Tube For Reduced TankWater Accumulation
Heavy Duty Metal Belt Guard
Industrial Grade Pressure Switch(Hubbell) And EATON Starter220volt/1phase, 40 Amp Breaker Required
1 Year Parts Only Warranty
Motor Running: 7.5 Horsepower
Delivered-CFM 90 PSI: 23
Delivered-CFM 175 PSI: 20
Pressure Setting: 145-175 PSI
Tank Capacity: 80 Gallons
Air Outlet Size: 3/4" NPT
Overall Dimensions: L 40" x W 24" x H 71"
Motor Voltage: 220volt, 1PH, 40 Amp Breaker,Number 8 Wire Required
Compressor Pump: 3 Cylinder, 2-Stage
Automatic Low Oil Monitor
Automatic Tank Drain
Air Cooled Aftercooler
Atlas Air Force AF9P is the perfect compressor for a large multi-bay auto shop�or for the small shop that wantsto be prepared for future growth. These are what we recommend for many auto shops of all sizes and is recommend for any business that depends on their air compressor to deliver flawlessly every business day.Atlas Air Force AF9P operate between 145-175 PSI. They come standard with a USA made 80 gallon steel tank andalso includes a magnetic starter. The magnetic starter controls the electric input and adds to the longevity of the unit.The Atlas Air Force air compressors are powerful, belt driven reciprocating air compressors designed and built to offer years of trouble-free service. The Atlas Air Force compressors are built to the same exacting standards as the entire line of Atlasprofessional grade automotive equipment.PLUS PACKAGE The Atlas Air Force AF9P includes the "Plus Package." The "Plus" features for our commercial grade twostage air compressors include an automatic low oil monitor, automatic tank drain, and air cooled aftercooler. These threefeatures help to extend the life of your Atlas air compressor while also delivering "better air".
